Cluster

Configuring gNMIc Cluster deployments

The Cluster resource defines a gNMIc collector deployment. It creates a StatefulSet, headless Service, Certificates, and manages the initial configuration for the gNMIc pods.

Basic Configuration

This CR creates a gNMIc cluster of 3 pods based on the referenced container image.

apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: telemetry-cluster
spec:
  replicas: 3
  image: ghcr.io/openconfig/gnmic:latest

Spec Fields

Field	Type	Required	Default	Description
`replicas`	int32	Yes	1	Number of gNMIc pods to run
`image`	string	Yes		Container image for gNMIc
API
`api`	APIConfig	No		REST API and gNMI server configurations
`api.restPort`	int32	No	7890	Port for REST API
`api.gnmiPort`	int32	No		Port for gNMI server (optional)
`api.tls`	ClusterTLSConfig	No		TLS for REST API (operator ↔ pods)
`api.tls.issuerRef`	string	No		CertManager Issuer reference, used to sign the REST API certificates
`api.tls.bundleRef`	string	No		ConfigMap reference, used to add API server trust bundles to the POD (key=`ca.crt`)
`api.tls.useCSIDriver`	bool	No		If true the API certificates are generated and mounted using CertManager CSI Driver
gNMI client TLS
`clientTLS`	ClusterTLSConfig	No		TLS for gNMI client (pods → targets)
`clientTLS.issuerRef`	string	No		CertManager Issuer reference, used to sign the gNMI client certificates
`clientTLS.bundleRef`	string	No		ConfigMap reference, used to add gNMI client trust bundles to the POD (key=`ca.crt`)
`clientTLS.useCSIDriver`	bool	No		If true the gNMI client certificates are generated and mounted using CertManager CSI Driver

Resource Configuration

Set resource requests and limits:

spec:
  resources:
    requests:
      memory: "128Mi"
      cpu: "100m"
    limits:
      memory: "512Mi"
      cpu: "1"

Environment Variables

Inject environment variables into pods:

spec:
  env:
    - name: GNMIC_DEBUG
      value: "true"
    - name: GNMIC_USERNAME
      valueFrom:
        secretKeyRef:
          name: gnmic-secrets
          key: username

gNMI Server

Enable the gNMI server for using the collecor as a gNMI Proxy/Cache

spec:
  api:
    gnmiPort: 9393

gRPC Tunnel Server

Enable gRPC tunnel mode for devices that initiate connections to the collector (reverse connectivity). This is useful when devices are behind NAT, firewalls, or when direct connectivity is not possible.

Basic Tunnel Configuration

apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: tunnel-cluster
spec:
  replicas: 3
  image: ghcr.io/openconfig/gnmic:latest
  grpcTunnel:
    port: 57400

Tunnel Fields

Field	Type	Required	Default	Description
`grpcTunnel.port`	in32	No		gRPC tunnel server port number
`grpcTunnel.tls.issuerRef`	string	No		CertManager Issuer reference, used to sign the gRPC Tunnel server certificates
`grpcTunnel.tls.bundleRef`	string	No		ConfigMap reference, used to add gRPC Tunnel server trust bundles to the POD (key=`ca.crt`)
`grpcTunnel.tls.useCSIDriver`	bool	No		If true the gRPC Tunnel server certificates are generated and mounted using CertManager CSI Driver
`grpcTunnel.service.type`	corev1.ServiceType	No	Loadbalancer	gRPC Tunnel Kubernetes Service type
`grpcTunnel.service.labels`	map[string]string	No		Set of labels to add to the create gRPC tunnel Service
`grpcTunnel.service.annotations`	map[string]string	No		Set of annotations to add to the create gRPC tunnel Service

Tunnel with TLS

spec:
  grpcTunnel:
    port: 57400
    tls:
      issuerRef: gnmic-ca-issuer
      bundleRef: client-ca-bundle  # Optional: for client cert verification

When bundleRef is set, client certificate authentication is required (gNMIc pod config will include a client-auth: require-verify under the tunnel-server.tls section).

Service Configuration

A kubernetes Service exposing the tunnel endpoints is automatically created when grpcTunnel is configured. It will have a default type loadbalancer but can be set to any of the supported kubernetes service types. The created service can be annotated to integrate with different load-balancer implementations (e.g metallb)

spec:
  grpcTunnel:
    port: 57400
    service:
      # The default is LoadBalancer since the devices
      # live outside of the kubernetes cluster in most cases.
      type: LoadBalancer
      # Annotations are useful to integrate
      # nicely with different load-balancer implementations
      annotations:
        metallb.io/address-pool: "production-pool"
        metallb.io/loadBalancerIPs: "10.1.1.100"
      labels:
        external-dns: "true"

Resources Created for gRPC Tunnel enabled clusters

Resource	Name Pattern	Purpose
Service	`gnmic-{cluster}-tunnel`	Exposes tunnel port to external devices
Certificate	`gnmic-{cluster}-{index}-tunnel-tls`	Per-pod tunnel TLS certificate (if TLS enabled)

Using Tunnel Targets

To collect telemetry from tunnel-connected devices, create TunnelTargetPolicy resources and reference them in a Pipeline. See the TunnelTargetPolicy documentation for details.

TLS Configuration

Enable TLS encryption for communication between the operator and gNMIc pods.

Prerequisites

cert-manager installed in your cluster
A CertManager Issuer configured in the cluster’s namespace

Basic TLS Setup

apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: secure-cluster
spec:
  replicas: 3
  image: ghcr.io/openconfig/gnmic:latest
  api:
    tls:
      issuerRef: gnmic-ca-issuer

TLS Fields

Field	Type	Description
`issuerRef`	string	Name of cert-manager Issuer in cluster’s namespace. It is used to sign the PODs REST API certificates.
`useCSIDriver`	bool	Use cert-manager CSI driver (default: false). When enabled the PODs certificates are issued and mounted using CertManager CSI driver instead of mounting Secrets.
`bundleRef`	string	Additional CA bundle for REST API client verification.

How It Works

When TLS is enabled:

Per-Pod Certificates: The operator creates a cert-manager Certificate for each pod
Automatic Mounting: Certificates are mounted at /etc/certs/api/
mTLS: The operator authenticates to pods using client certificates
CA Sync: The operator’s CA is synced to the cluster namespace as a ConfigMap

Creating a CA Issuer

First, create a self-signed issuer and CA (or reuse one of your preexisting issers)

# Self-signed issuer for bootstrapping
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
  name: selfsigned-issuer
spec:
  selfSigned: {}
---
# CA certificate
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: gnmic-ca
spec:
  isCA: true
  commonName: gnmic-ca
  secretName: gnmic-ca-secret
  privateKey:
    algorithm: ECDSA
    size: 256
  issuerRef:
    name: selfsigned-issuer
    kind: Issuer
---
# CA Issuer for pod certificates
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
  name: gnmic-ca-issuer
spec:
  ca:
    secretName: gnmic-ca-secret

Using CSI Driver

For enhanced security, use the cert-manager CSI driver (generated certificates are never written to disk):

spec:
  api:
    tls:
      issuerRef: gnmic-ca-issuer
      useCSIDriver: true

Note: Requires cert-manager-csi-driver to be installed.

Resources Created for TLS

When TLS is enabled, additional resources are created:

Resource	Name Pattern	Purpose
Certificate	`gnmic-{cluster}-{index}-tls`	Per-pod TLS certificate
Secret	`gnmic-{cluster}-{index}-tls`	Certificate and key (created by cert-manager)
ConfigMap	`gnmic-{cluster}-controller-ca`	Controller’s CA for mTLS verification

gNMI Client TLS (Target Connections)

Enable TLS client certificates for gNMIc pods to authenticate to network devices using mTLS. This is separate from the API TLS which secures operator-to-pod communication.

When to Use Client TLS

Your network devices require client certificate authentication
You want mutual TLS (mTLS) between gNMIc and targets
Your security policy mandates certificate-based authentication for gNMI connections

Basic Client TLS Setup

apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: mtls-cluster
spec:
  replicas: 3
  image: ghcr.io/openconfig/gnmic:latest
  clientTLS:
    issuerRef: gnmic-client-ca-issuer

Client TLS Fields

Field	Type	Description
`issuerRef`	string	Name of cert-manager Issuer to sign client certificates
`useCSIDriver`	bool	Use cert-manager CSI driver (default: false)
`bundleRef`	string	ConfigMap containing CA bundle for verifying target server certificates

How It Works

When clientTLS is configured:

Per-Pod Client Certificates: The operator creates a cert-manager Certificate with ClientAuth usage for each pod
Automatic Mounting: Client certificates are mounted at /etc/gnmic/client-tls/
Target Configuration: All target configs automatically include the client certificate paths
CA Bundle (optional): If bundleRef is set, it’s mounted at /etc/gnmic/client-ca/ for verifying target server certificates

Client TLS with CA Verification

To verify target server certificates (recommended for production):

spec:
  clientTLS:
    issuerRef: gnmic-client-ca-issuer
    bundleRef: target-ca-bundle  # ConfigMap with CA certificates

Create the CA bundle ConfigMap:

kubectl create configmap target-ca-bundle --from-file=ca.crt=/path/to/target-ca.crt

Using CSI Driver for Client TLS

For enhanced security (certificates never written to disk):

spec:
  clientTLS:
    issuerRef: gnmic-client-ca-issuer
    useCSIDriver: true

Resources Created for Client TLS

Resource	Name Pattern	Purpose
Certificate	`gnmic-{cluster}-{index}-client-tls`	Per-pod gNMI client certificate
Secret	`gnmic-{cluster}-{index}-client-tls`	Client certificate and key (created by cert-manager)

Example: Full mTLS Setup

# CA Issuer for client certificates
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
  name: gnmic-client-ca-issuer
spec:
  ca:
    secretName: gnmic-client-ca-secret
---
# Cluster with both API TLS and Client TLS
apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: secure-telemetry
spec:
  replicas: 3
  image: ghcr.io/openconfig/gnmic:latest
  api:
    restPort: 7890
    tls:
      issuerRef: gnmic-api-ca-issuer  # For operator ↔ pod communication
  clientTLS:
    issuerRef: gnmic-client-ca-issuer  # For pod → target gNMI connections
    bundleRef: target-ca-bundle        # To verify target server certs

Difference: API TLS vs Client TLS

Aspect	API TLS (`api.tls`)	Client TLS (`clientTLS`)
Purpose	Secure operator ↔ pod REST API	Secure pod → target gNMI
Direction	Operator connects to pods	Pods connect to targets
Certificate Usage	Server + Client Auth	Client Auth only
Mount Path	`/etc/gnmic/tls/`	`/etc/gnmic/client-tls/`
Applied To	gNMIc REST API server	All gNMI target connections

Created Resources

When you create a Cluster, the operator creates:

Resource	Name	Purpose
StatefulSet	`gnmic-{cluster-name}`	Runs gNMIc pods
Service (Headless)	`gnmic-{cluster-name}`	Pod DNS resolution
ConfigMap	`gnmic-{cluster-name}-config`	Base gNMIc configuration
Service (per Prometheus output)	`gnmic-{cluster-name}-prom-{output}`	Prometheus metrics endpoint

Status

The Cluster status shows the current state:

status:
  readyReplicas: 3
  pipelinesCount: 2
  targetsCount: 10
  subscriptionsCount: 5
  inputsCount: 1
  outputsCount: 3
  conditions:
    - type: Ready
      status: "True"
      reason: ClusterReady
      message: "All 3 replicas are ready and configured"
    - type: ConfigApplied
      status: "True"
      reason: ConfigurationApplied
      message: "Configuration applied to 3 pods"

Status Fields

Field	Description
`readyReplicas`	Number of pods that are ready
`pipelinesCount`	Number of enabled pipelines using this cluster
`targetsCount`	Total unique targets across all pipelines
`subscriptionsCount`	Total unique subscriptions
`inputsCount`	Total unique inputs
`outputsCount`	Total unique outputs
`conditions`	Standard Kubernetes conditions

Conditions

Type	Description
`Ready`	True when all replicas are ready and configured
`CertificatesReady`	True when TLS certificates are issued (only present if TLS enabled)
`ConfigApplied`	True when configuration is successfully applied to all pods

Scaling

To scale the cluster, update the replicas field:

kubectl patch cluster telemetry-cluster --type merge -p '{"spec":{"replicas":5}}'

Targets are automatically redistributed across pods when scaling.

Example: Production Cluster

apiVersion: operator.gnmic.dev/v1alpha1
kind: Cluster
metadata:
  name: production-telemetry
  namespace: telemetry
spec:
  replicas: 5
  image: ghcr.io/openconfig/gnmic:latest
  api:
    restPort: 7890
    tls:
      issuerRef: gnmic-op-issuer
      useCSIDriver: true
  resources:
    requests:
      memory: "256Mi"
      cpu: "200m"
    limits:
      memory: "1Gi"
      cpu: "2"
